Butt jointing Machine
AKIRA® Electrofusion Welding Machine is designed for secure and reliable joining of PE pipes and fittings using electrofusion couplers. It is widely used in gas and water supply pipelines, ensuring strong, leak-proof, and durable joints even in demanding site conditions.
Engineered as per ISO 12176 international electrofusion welding standards, this machine delivers accuracy, safety, and ease of operation for field and workshop applications.
Key Features
- ISO 12176 Standard Design - Manufactured and tested according to ISO 12176 electrofusion welding standards, ensuring consistent welding quality and global compliance.
- Advanced MCU Control System - High-level MCU acts as the control core, providing precise control over the welding process for reliable and repeatable results.
- LCD Display with Real-Time Parameters - Clear LCD screen displays all welding parameters in real time, allowing operators to monitor voltage, time, and welding status easily.
- Lightweight & Portable - Compact and lightweight design makes the machine easy to carry, transport, and operate on-site or in confined spaces.
- Real-Time Weld Monitoring - The system continuously monitors the welding process.
If any abnormal condition is detected, the welding cycle is automatically terminated to prevent faulty joints.
- Built-In Welding Data Memory - memory can store over 500 welding records, ensuring complete traceability for quality audits and project documentation.
- USB Data Export (Optional) - Stored welding data can be downloaded via USB flash drive, making reporting and record-keeping simple and efficient.
- Error-Free Wiring Design - Simple and intuitive wiring layout reduces the risk of connection errors and speeds up setup time.
- Flexible Parameter Input Modes -
Manual Input Mode – Enter welding parameters directly
Barcode Scanner Mode – Automatically read welding data from fittings (faster & error-free)
Machine Specification
| Model |
AKIRA200 |
AKIRA315 |
AKIRA500 |
AKIRA800 |
| Welding Range (mm) |
20-200mm |
20-315mm |
20-500mm |
20-800mm |
| Input Voltage (V) |
AC 170-250 50Hz |
| Output Power(KW) |
2KW |
3KW |
5KW |
11KW |
| Output Voltage(KW) |
8-48V |
| Control Mode |
Constant Current/Constant Voltage |
| Temp. Measuring Precision (°C) |
+0.5°C |
| Weight (KG) |
20 |
25 |
28 |
18 |
Compatible Pipe & Fitting Types
The AKIRA® Electrofusion Butt Jointing Machine is compatible with a wide range of PE piping systems, ensuring reliable and secure connections for gas and water supply applications.
- PE80 & PE100 pipes for gas and water supply
- Electrofusion couplers, elbows, tees, reducers & end caps
- Supports manual and barcode-enabled electrofusion fittings
Standard & Optional Accessories
- Electrofusion Welding Machine Unit
- Welding Output Cables
- Power Input Cable
- LCD Display Control Panel (Built-in)
- Operation & User Manual
Optional Accessories
- Barcode Scanner for Automatic Parameter Input
- USB Flash Drive Data Export Function
- Protective Carrying Case
- Extended Welding Cables (on request)
Optional accessories enhance ease of operation, data traceability, and field efficiency, especially for large pipeline projects.
Applications
- ✔ Gas Distribution Pipelines
- ✔ Municipal Water Supply Systems
- ✔ Industrial PE Piping Networks
- ✔ Repair & Maintenance of PE Pipelines
- ✔ Underground & Utility Infrastructure Projects
Why Choose AKIRA® Electrofusion Welding Machine?
- ✔ ISO-compliant and industry-approved
- ✔ Safe and controlled welding process
- ✔ High accuracy with minimal operator dependency
- ✔ Portable and site-friendly design
- ✔ Complete welding data traceability
